Basic Function of DIN-Rail RS232 to Ethernet Converter USR-DR301
Realize bidirectional transparent transmission
between RS232 and Ethernet
![DIN-Rail mounting feature](/d/file/20191030/9584c11f1cd317d7812f5c11e3f05426.jpg)
DIN-Rail mounted RS232 to Ethernet Converter USR-DR301
Small size, easy to manage and maintain, cost-effective
![Function Diagram of DIN-Rail RS232 serial to Ethernet converter USR-DR301](/d/file/20191030/46a1329bb159f4588dde205b67fe5964.jpg)
Function Diagram
![Working mode of DIN-Rail RS232 serial to Ethernet converter USR-DR301](/d/file/20191030/fda29f277c1c08fe4ca02716c7dec5b2.jpg)
Working mode
Serial to Ethernet converter USR-DR301 will initiate TCP connection to the destination IP address
that configured by the user and serial to Ethernet converter will continuously try to reconnect
if establishing TCP connection unsuccessfully.
![Working mode of USR-DR301: TCP client](/d/file/20191030/5497b1d2cbcc0bc7ae549fe8182cc325.jpg)
Serial to Ethernet converter USR-DR301 monitors the set port and waits
for a TCP client connection. Data from the serial device will transmit
to all successfully-connected via serial to Ethernet converter.
![Working mode of USR-DR301: TCP Server](/d/file/20191105/95888f7ccbbff3b0a8608dfdce9ca05e.jpg)
USR-DR301 only communicates with the target interface of the target IP,
thus to assure the accuracy of data transmission.
![Working mode of USR-DR301: UDP Server](/d/file/20191105/c35912c244ea2330fecc1fdf970ec91f.jpg)
DR301 can transmit the data automatically to the last time transferred
device after receiving the data, which is suitable for multi-network
devices that need to communicate with the DR301.
![Working mode of USR-DR301: httpsD Client](/d/file/20191030/6221e6a441a58e8145021794adce5af8.jpg)
DR301 supports the function of transmitting the serial data to the
specified server in the form of httpsD (GET/POST).
![DIN-Rail RS232 serial to Ethernet converter USR-DR301 supports Modbus gateway function](/d/file/20191030/43f4b090bcfac4522041c257e4fd5d21.jpg)
Support Modbus gateway
![More functions of DIN-Rail RS232 serial to Ethernet converter USR-DR301: Virtual serial software,Network Heartbeat Packet](/d/file/20191030/60e762f7db5c67f3717d065704b551d0.jpg)
More functions
Virtual serial software
Solve the problem of PC software
as a serial port can not communicate
with networking device.
Network Heartbeat Packet
Serial server maintains the normal
connection with the server by sending
heartbeat packet regularly.
![DIN-Rail RS232 serial to Ethernet converter USR-DR301 functions:Identity Heartbeat Packet,USRIOT Cloud](/d/file/20191030/410791cf7501c0daa9bc83305622bf66.jpg)
Identity Heartbeat Packet
When 301 works as TCP Client, it can send identity packet
packet to TCP server which can be identification.
Identity packet can be IMEI code, ICCID code
and user editable identity packet.
USRIOT Cloud
USR-DR301 can realize the bidirectional transparent
transmission between the server and terminal device
through USRIOT Cloud quickly.
![Product details of DIN-Rail RS232 serial to Ethernet converter: PC+ABSC material, portable, low cost, V0 flame retardant](/d/file/20200312/46af5db3f6419f245adf5fb2e914f6fc.jpg)
Product details
PC+ABSC material, portable, low cost, V0 flame retardant,
ensure the safety of the product.
![Application of DIN-Rail RS232 serial to Ethernet converter USR-DR301:Power data networking transmission](/d/file/20191030/ab1ee758ea3cc3e1c96c35bb411b776b.jpg)
Power data networking transmission
Small size which is available for narrow space;
DIN-Rail mounting, easy to install on the wall;
The terminal data of the distribution box can quickly convert into the network data,
real-time communication, reduce the cost effectively.
![Application of DIN-Rail RS232 serial to Ethernet converter USR-DR301: Unattended Weighing](/d/file/20191030/c36b47370fcb8c390e6fc6879c6beb4d.jpg)
Unattended Weighing
Connect serial to ethernet converter USR-DR301 to barrier gate and it can realize remote control
of barrier gate by Ethernet in control center.
![Application of DIN-Rail RS232 serial to Ethernet converter USR-DR301:Traffic Lights Management System](/d/file/20191030/cd2408cda354d5cf74f75f789f0c866d.jpg)
Traffic Lights Management System
Connect serial to Ethernet converter USR-DR301, and it can realize traffic data acquisition and
processing by Ethernet in the control center. And the control room personnel can quickly
make traffic scheduling and planning according to the site condition.
